644312-2
RoHS
/
Package /
Category Connectors, Interconnects / Rectangular Connectors - Free Hanging, Panel Mount
Description
Headers & Wire Housings 02P MTA100 CONN ASSY POL TAB
PDF
/
Inventory: 2018
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Contact Material COPPER ALLOY
Contact Plating Lead, Tin
Mount Cable
Housing Material Nylon
Technical
JESD-609 Code e0
Termination IDC
ECCN Code EAR99
Connector Type Connector, Receptacle, Socket
Max Operating Temperature 221°C
Min Operating Temperature -67°C
Number of Rows 1
HTS Code 8536.69.40.40
Subcategory Headers and Edge Type Connectors
Contact Finish - Mating TIN LEAD
MIL Conformance NO
DIN Conformance NO
IEC Conformance NO
Filter Feature NO
Mixed Contacts NO
Option GENERAL PURPOSE
Pitch 2.54mm
Orientation Right Angle
Voltage - Rated AC 250V
Reliability COMMERCIAL
Approval Agency CSA
Shrouding No
Number of Contacts 2
Mating Information MULTIPLE MATING PARTS AVAILABLE
Contact Gender Female
UL Flammability Code 94V-0
Housing Color Black
Rated Current (Signal) 5A
Contact Style SQ PIN-SKT
Contact Resistance 6mOhm
ELV Non-Compliant
Max Voltage Rating (AC) 250V
Polarization Key POLARIZED HOUSING
Dielectric Withstanding Voltage 750VAC V
Wire/Cable Gauge 24 AWG
Contact Pattern RECTANGULAR
Insertion Force-Max 8.896 N
Insulation Diameter 1.52 mm
Contact Rating (Current) 5A
Dimensions
Height 6.99mm
Length 5.08mm
Plating Thickness 5.08μm
Compliance
RoHS Status RoHS Compliant
Flammability Rating UL94 V-0
Lead Free Not Applicable
