644083-2
RoHS
/
Package /
Category Connectors, Interconnects / Rectangular Connectors - Free Hanging, Panel Mount
Description
CONN RECEPT 2POS POL MTA-100 TIN
PDF
/
Inventory: 4664
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Not Applicable
Flammability Rating UL94 V-0
RoHS Status RoHS Compliant
Dimensions
Plating Thickness 5.08μm
Length 5.08mm
Height 6.99mm
Technical
Contact Rating (Current) 5A
Insulation Diameter 1.52 mm
Insertion Force-Max 8.896 N
Contact Pattern RECTANGULAR
Wire/Cable Gauge 22 AWG
Wire/Cable Type Discrete
Dielectric Withstanding Voltage 750VAC V
Polarization Key POLARIZED HOUSING
Max Voltage Rating (AC) 250V
ELV Non-Compliant
Contact Resistance 6mOhm
Contact Style SQ PIN-SKT
UL Flammability Code 94V-0
Contact Gender Female
Mating Information MULTIPLE MATING PARTS AVAILABLE
Number of Contacts 2
Lead Pitch 2.54mm
Shrouding No
Approval Agency CSA
Reliability COMMERCIAL
Voltage - Rated AC 250V
Reference Standard UL
Current Rating 5A
Orientation Right Angle
Pitch 2.54mm
Option GENERAL PURPOSE
Mixed Contacts NO
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Subcategory Headers and Edge Type Connectors
Fastening Type Ramp
HTS Code 8536.69.40.40
Number of Rows 1
Color Black
Min Operating Temperature -67°C
Max Operating Temperature 221°C
Connector Type Connector, Receptacle, Socket
ECCN Code EAR99
Termination IDC
Pbfree Code no
JESD-609 Code e0
Packaging Bulk
Physical
Housing Material Nylon
Mount Cable, Free Hanging
Contact Plating Lead, Tin
Contact Material COPPER ALLOY
