643818-9
RoHS
/
Package /
Category Connectors, Interconnects / Rectangular Connectors - Free Hanging, Panel Mount
Description
CONN RECEPT 9POS MTA-156 20AWG
PDF
/
Buying Options
Total Price: USD $1.75
Unit Price: USD $1.745074
≥1 USD $1.745074
≥10 USD $1.646297
≥100 USD $1.55311
≥500 USD $1.46519
≥1000 USD $1.382262
Inventory: 1484
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Not Applicable
Flammability Rating UL94 V-2
RoHS Status RoHS Compliant
Dimensions
Plating Thickness 80μm
Width 9.02mm
Length 35.66mm
Height 9.02mm
Technical
Contact Rating (Current) 7A
Insulation Diameter 2.413 mm
Insertion Force-Max 8.0064 N
Contact Pattern RECTANGULAR
Wire/Cable Gauge 20 AWG
Durability 25 Cycles
Wire/Cable Type Discrete
Dielectric Withstanding Voltage 2200VAC V
Polarization Key POLARIZED HOUSING
Max Voltage Rating (AC) 600V
ELV Non-Compliant
Contact Resistance 3mOhm
Contact Style SQ PIN-SKT
Rated Current (Signal) 7A
Contact Gender Female
Body Breadth 0.355 inch
Shrouding No
Approval Agency CSA
Reliability COMMERCIAL
Voltage - Rated AC 600V
Current Rating 7A
Depth 9.02mm
Orientation Right Angle
Total Number of Contacts 9
Pitch 3.9624mm
Option GENERAL PURPOSE
Mixed Contacts NO
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Subcategory Headers and Edge Type Connectors
Fastening Type Ramp
Gender Receptacle
Number of Rows 1
Color Yellow
Min Operating Temperature -67°C
Max Operating Temperature 221°C
Number of Positions 9
Connector Type Socket
Termination IDC
Pbfree Code no
JESD-609 Code e0
Packaging Bulk
Physical
Housing Material Nylon
Mount Cable, Free Hanging
Contact Plating Tin
Contact Material COPPER ALLOY
