643816-6 image
Favorite
643816-6 image
Favorite
RoHS
/
Package /
Category Connectors, Interconnects / Rectangular Connectors - Free Hanging, Panel Mount
Description CONN RECEPT 6POS 28AWG MTA100
PDF
/
Buying Options
Total Price: USD $0.6
Unit Price: USD $0.601655
≥1 USD $0.601655
≥10 USD $0.567599
≥100 USD $0.535466
≥500 USD $0.505153
≥1000 USD $0.476565
Inventory: 3794
Minimum: 1
-
+

Technical Details

Physical

Contact Material COPPER ALLOY
Contact Plating Tin
Mount Cable, Free Hanging
Housing Material Nylon

Technical

Packaging Bulk
JESD-609 Code e0
Pbfree Code no
Termination IDC
Connector Type Connector, Receptacle, Socket
Max Operating Temperature 221°C
Min Operating Temperature -67°C
Color Green
Number of Rows 1
Gender Receptacle
Fastening Type Ramp
Subcategory Headers and Edge Type Connectors
MIL Conformance NO
DIN Conformance NO
IEC Conformance NO
Filter Feature NO
Mixed Contacts NO
Option GENERAL PURPOSE
Pitch 2.54mm
Orientation Right Angle
Depth 6.99mm
Current Rating 5A
Voltage - Rated AC 250V
Reliability COMMERCIAL
Approval Agency CSA
Shrouding No
Number of Contacts 6
Body Breadth 0.275 inch
Contact Gender Female
UL Flammability Code 94V-2
Housing Color Green, White
Contact Style SQ PIN-SKT
Contact Resistance 6mOhm
ELV Non-Compliant
Max Voltage Rating (AC) 250V
Polarization Key POLARIZED HOUSING
Dielectric Withstanding Voltage 750VAC V
Wire/Cable Type Discrete
Durability 25 Cycles
Wire/Cable Gauge 28 AWG
Contact Pattern RECTANGULAR
Insulation Diameter 1.52 mm
Contact Rating (Current) 5A

Dimensions

Height 6.99mm
Length 15.24mm
Plating Thickness 5.08μm

Compliance

RoHS Status RoHS Compliant
Flammability Rating UL94 V-2
Lead Free Not Applicable
