RoHS
/
Package /
Category Connectors, Interconnects / Rectangular Connectors - Free Hanging, Panel Mount
Description Rectangular Connector Panel Mount
PDF
/
Inventory: 9181
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Physical

Contact Material PHOSPHOR BRONZE
Contact Plating Tin
Housing Material Nylon
Mounting Option 1 LOCKING
Underplate Material Nickel

Technical

Packaging Bulk
JESD-609 Code e3
Pbfree Code no
Termination IDC
Connector Type Connector, Receptacle, Socket
Max Operating Temperature 221°C
Min Operating Temperature -67°C
Number of Rows 1
Subcategory Headers and Edge Type Connectors
Contact Finish - Mating TIN
MIL Conformance NO
DIN Conformance NO
IEC Conformance NO
Filter Feature NO
Mixed Contacts NO
Option GENERAL PURPOSE
Pitch 3.9624mm
Current Rating 7A
Voltage - Rated AC 600V
Reliability COMMERCIAL
Approval Agency CSA
Shrouding No
Number of Contacts 5
Contact Gender Female
UL Flammability Code 94V-2
Housing Color Red
Rated Current (Signal) 7A
Contact Style SQ PIN-SKT
ELV Non-Compliant
Polarization Key POLARIZED HOUSING
Wire/Cable Gauge 22 AWG
Contact Pattern RECTANGULAR
Withdrawl Force-Min .8896 N
Insulator Color RED
Insulation Diameter 2.41 mm
Contact Rating (Current) 7A

Dimensions

Height 9.02mm
Length 19.81mm
Plating Thickness 5.08μm

Compliance

RoHS Status RoHS Compliant
Flammability Rating UL94 V-2
Lead Free Not Applicable
