641818-5
RoHS
/
Package /
Category Connectors, Interconnects / Rectangular Connectors - Free Hanging, Panel Mount
Description
Free Hanging Rectangular Connector
PDF
/
Inventory: 4748
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Not Applicable
Flammability Rating UL94 V-2
RoHS Status RoHS Compliant
Dimensions
Plating Thickness 5.08μm
Length 12.7mm
Height 6.99mm
Technical
Wire Size (Max) 22 AWG
Contact Rating (Current) 5A
Insulation Diameter 1.52 mm
Insertion Force-Max 8.896 N
Contact Pattern RECTANGULAR
Wire/Cable Gauge 24 AWG
Polarization Key POLAR PIN POSITION
ELV Non-Compliant
Body/Shell Style PLUG
Contact Resistance 6mOhm
Contact Style SQ PIN-SKT
Rated Current (Signal) 5A
Housing Color White
UL Flammability Code 94V-2
Contact Gender Female
Number of Contacts 5
Shrouding No
Approval Agency CSA
Reliability COMMERCIAL
Voltage - Rated AC 250V
Current Rating 5A
Pitch 2.54mm
Option GENERAL PURPOSE
Mixed Contacts NO
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Subcategory Headers and Edge Type Connectors
Number of Rows 1
Min Operating Temperature -67°C
Max Operating Temperature 221°C
Connector Type Connector, Receptacle, Socket
ECCN Code EAR99
Termination IDC
Pbfree Code no
JESD-609 Code e0
Packaging Bulk
Physical
Housing Material Nylon
Contact Plating Lead, Tin
Contact Material COPPER ALLOY
