641536-5
RoHS
/
Package /
Category Connectors, Interconnects / Rectangular Connectors - Free Hanging, Panel Mount
Description
Rectangular Connector Panel Mount
PDF
/
Inventory: 9130
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Contact Material COPPER ALLOY
Contact Plating Lead, Tin
Housing Material Nylon
Mounting Option 1 LOCKING
Technical
Packaging Bulk
JESD-609 Code e0
Pbfree Code no
Termination IDC
ECCN Code EAR99
Connector Type Connector, Receptacle, Socket
Max Operating Temperature 221°C
Min Operating Temperature -67°C
Number of Rows 1
Gender Female
Subcategory Headers and Edge Type Connectors
MIL Conformance NO
DIN Conformance NO
IEC Conformance NO
Filter Feature NO
Mixed Contacts NO
Option GENERAL PURPOSE
Pitch 2.54mm
Reference Standard UL
Voltage - Rated AC 250V
Reliability COMMERCIAL
Approval Agency CSA
Shrouding No
Number of Contacts 5
UL Flammability Code 94V-2
Housing Color White
Rated Current (Signal) 5A
Contact Style SQ PIN-SKT
ELV Non-Compliant
Polarization Key POLARIZED HOUSING
Wire/Cable Gauge 26 AWG
Contact Pattern RECTANGULAR
Insertion Force-Max 8.896 N
Withdrawl Force-Min 3.336 N
Insulator Color BLUE
Insulation Diameter 1.52 mm
Contact Rating (Current) 5A
Contact Design PREASSEM CONN
Dimensions
Height 6.99mm
Length 12.7mm
Plating Thickness 2.03μm
Compliance
RoHS Status RoHS Compliant
Flammability Rating UL94 V-2
Lead Free Not Applicable
