641222-7
RoHS
/
Package /
Category Connectors, Interconnects / Rectangular Connectors - Free Hanging, Panel Mount
Description
AMP Free Hanging Rectangular Connector
PDF
/
Inventory: 3368
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Not Applicable
Flammability Rating UL94 V-2
RoHS Status RoHS Compliant
Dimensions
Length - Termination 0.48 inch
Plating Thickness 30μin
Technical
Wire Size (Max) 22 AWG
Wire Size (Min) 22 AWG
Contact Pattern RECTANGULAR
Wire/Cable Gauge 18 AWG
ELV Compliant
Body/Shell Style PLUG
Insulation Resistance 5000000Ohm
Contact Resistance 3mOhm
Contact Style SQ PIN-SKT
Body Depth 0.355 inch
Housing Color Orange
UL Flammability Code 94V-2
Operating Temperature (Min) -55°C
Contact Gender Female
Mating Information MULTIPLE MATING PARTS AVAILABLE
Number of Contacts 7
Shrouding No
Reliability COMMERCIAL
Voltage - Rated AC 600V
Reference Standard UL, CSA
Current Rating 7A
Pitch 3.96mm
Option GENERAL PURPOSE
Mixed Contacts NO
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Subcategory Headers and Edge Type Connectors
HTS Code 8536.69.40.40
Additional Feature AMP
Number of Rows 1
Connector Type Connector, Receptacle, Socket
ECCN Code EAR99
Termination IDC
Pbfree Code no
JESD-609 Code e0
Physical
Housing Material Nylon
Contact Plating Gold
Contact Material PHOSPHOR BRONZE
