641219-9
RoHS
/
Package /
Category Connectors, Interconnects / Rectangular Connectors - Free Hanging, Panel Mount
Description
Headers & Wire Housings 09P MTA156 CONN ASSY 22AWG RED
PDF
/
Inventory: 4164
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Not Applicable
Flammability Rating UL94 V-2
RoHS Status RoHS Compliant
Technical
Contact Pattern RECTANGULAR
Wire/Cable Gauge 22 AWG
Durability 25 Cycles
Wire/Cable Type Discrete
Dielectric Withstanding Voltage 2200VAC V
Polarization Key POLARIZED HOUSING
ELV Compliant
Insulation Resistance 5000000000Ohm
Contact Resistance 3mOhm
Contact Style SQ PIN-SKT
Rated Current (Signal) 7A
Body Depth 0.725 inch
Housing Color White
Operating Temperature (Min) -55°C
Contact Gender Female
Body Breadth 0.355 inch
Mating Information MULTIPLE MATING PARTS AVAILABLE
Number of Contacts 9
Shrouding No
Reliability COMMERCIAL
Voltage - Rated AC 600V
Reference Standard UL, CSA
Current Rating 7A
Pitch 3.96mm
Option GENERAL PURPOSE
Mixed Contacts NO
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Subcategory Headers and Edge Type Connectors
Fastening Type Ramp
Additional Feature AMP
Number of Rows 1
Color Red
Connector Type Connector, Receptacle, Socket
Termination IDC
Pbfree Code no
JESD-609 Code e0
Packaging Bulk
Physical
Housing Material Nylon
Mount Free Hanging
Contact Plating Gold
Contact Material PHOSPHOR BRONZE
