641150-5
RoHS
/
Package /
Category Connectors, Interconnects / Rectangular Connectors - Free Hanging, Panel Mount
Description
Headers & Wire Housings 05P MTA156 CONN ASSY 22AWG RED
PDF
/
Inventory: 6581
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Contact Material PHOSPHOR BRONZE
Contact Plating Gold
Mount Cable, Free Hanging
Housing Material Nylon
Technical
Packaging Bulk
JESD-609 Code e0
Pbfree Code no
Termination IDC
ECCN Code EAR99
Connector Type Connector, Receptacle, Socket
Max Operating Temperature 105°C
Min Operating Temperature -55°C
Color Red
Number of Rows 1
Additional Feature AMP
Fastening Type Ramp
Subcategory Headers and Edge Type Connectors
MIL Conformance NO
DIN Conformance NO
IEC Conformance NO
Filter Feature NO
Mixed Contacts NO
Option GENERAL PURPOSE
Pitch 3.96mm
Orientation Right Angle
Current Rating 7A
Reference Standard UL, CSA
Voltage - Rated AC 600V
Reliability COMMERCIAL
Shrouding No
Number of Contacts 5
Mating Information MULTIPLE MATING PARTS AVAILABLE
Contact Gender Female
UL Flammability Code 94V-2
Housing Color Red, White
Rated Current (Signal) 7A
Contact Style SQ PIN-SKT
Contact Resistance 3mOhm
Body/Shell Style PLUG
ELV Compliant
Max Voltage Rating (AC) 600V
Wire/Cable Type Discrete
Wire/Cable Gauge 22 AWG
Contact Pattern RECTANGULAR
Withdrawl Force-Min .4448 N
Dimensions
Height 18.4mm
Length 19.8mm
Width 9.02mm
Compliance
RoHS Status RoHS Compliant
Flammability Rating UL94 V-2
Lead Free Not Applicable
