641148-6
RoHS
/
Package /
Category Connectors, Interconnects / Rectangular Connectors - Free Hanging, Panel Mount
Description
Headers & Wire Housings 06P MTA156 CONN ASSY 18AWG ORA
PDF
/
Inventory: 5766
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Contact Material PHOSPHOR BRONZE
Contact Plating Gold
Mount Free Hanging
Housing Material Nylon
Technical
Packaging Bulk
JESD-609 Code e0
Pbfree Code no
Termination IDC
ECCN Code EAR99
Connector Type Connector, Receptacle, Socket
Color Orange
Number of Rows 1
Additional Feature AMP
Fastening Type Ramp
Subcategory Headers and Edge Type Connectors
MIL Conformance NO
DIN Conformance NO
IEC Conformance NO
Filter Feature NO
Mixed Contacts NO
Option GENERAL PURPOSE
Pitch 3.96mm
Current Rating 7A
Reference Standard UL, CSA
Voltage - Rated AC 600V
Reliability COMMERCIAL
Shrouding No
Number of Contacts 6
Mating Information MULTIPLE MATING PARTS AVAILABLE
Body Breadth 0.355 inch
Contact Gender Female
Operating Temperature (Min) -55°C
UL Flammability Code 94V-2
Housing Color White
Body Depth 0.725 inch
Rated Current (Signal) 7A
Contact Style SQ PIN-SKT
Contact Resistance 3mOhm
Insulation Resistance 5000000000Ohm
Body/Shell Style PLUG
ELV Compliant
Wire/Cable Type Discrete
Durability 25 Cycles
Wire/Cable Gauge 18 AWG
Contact Pattern RECTANGULAR
Insertion Force-Max 5.7824 N
Withdrawl Force-Min .4448 N
Compliance
RoHS Status RoHS Compliant
Flammability Rating UL94 V-2
Lead Free Not Applicable
