640604-2
RoHS
/
Package /
Category Connectors, Interconnects / Rectangular Connectors - Free Hanging, Panel Mount
Description
CONN RECEPT 2POS MTA-156 18AWG
PDF
/
Buying Options
Total Price: USD $0.24
Unit Price: USD $0.241824
≥1 USD $0.241824
≥10 USD $0.228135
≥100 USD $0.215217
≥500 USD $0.203041
≥1000 USD $0.191547
Inventory: 6234
Minimum: 1
-
+
Technical Details
Physical
Contact Material COPPER ALLOY
Contact Plating Lead, Tin
Mount Cable, Free Hanging
Housing Material Nylon
Technical
Packaging Bulk
JESD-609 Code e0
Pbfree Code no
Termination IDC
ECCN Code EAR99
Connector Type Socket
Number of Positions 2
Max Operating Temperature 221°C
Min Operating Temperature -67°C
Color Orange
Number of Rows 1
HTS Code 8536.69.40.40
Subcategory Headers and Edge Type Connectors
MIL Conformance NO
DIN Conformance NO
IEC Conformance NO
Filter Feature NO
Mixed Contacts NO
Option GENERAL PURPOSE
Pitch 3.9624mm
Total Number of Contacts 2
Orientation Right Angle
Depth 9.78mm
Current Rating 7A
Reference Standard UL
Voltage - Rated AC 600V
Reliability COMMERCIAL
Approval Agency CSA
Shrouding No
Mating Information MULTIPLE MATING PARTS AVAILABLE
Body Breadth 0.385 inch
Contact Gender Female
Rated Current (Signal) 7A
Contact Style SQ PIN-SKT
Contact Resistance 3mOhm
Body/Shell Style RECEPTACLE
ELV Non-Compliant
Max Voltage Rating (AC) 600V
Polarization Key POLARIZED HOUSING
Wire/Cable Type Discrete
Wire/Cable Gauge 18 AWG
Contact Pattern RECTANGULAR
Insertion Force-Max 8.0064 N
Withdrawl Force-Min .8896 N
Insulation Diameter 2.413 mm
Contact Rating (Current) 7A
Dimensions
Height 9.78mm
Length 7.9248mm
Plating Thickness 80μm
Compliance
RoHS Status RoHS Compliant
Flammability Rating UL94 V-2
Lead Free Not Applicable
