640433-9 image
Favorite
640433-9 image
Favorite
RoHS
/
Package /
Category Connectors, Interconnects / Rectangular Connectors - Free Hanging, Panel Mount
Description CONN RECEPT 9POS MTA-156 22AWG
PDF
/
Buying Options
Total Price: USD $0.66
Unit Price: USD $0.663377
≥1 USD $0.663377
≥10 USD $0.625828
≥100 USD $0.590397
≥500 USD $0.556981
≥1000 USD $0.525457
Inventory: 5954
Minimum: 1
-
+

Technical Details

Physical

Contact Material COPPER ALLOY
Contact Plating Lead, Tin
Mount Cable, Free Hanging
Housing Material Nylon

Technical

Packaging Bulk
JESD-609 Code e0
Pbfree Code no
Termination IDC
Connector Type Connector, Receptacle, Socket
Max Operating Temperature 221°C
Min Operating Temperature -67°C
Color Red
Number of Rows 1
Subcategory Headers and Edge Type Connectors
Contact Finish - Mating TIN LEAD
MIL Conformance NO
DIN Conformance NO
IEC Conformance NO
Filter Feature NO
Mixed Contacts NO
Option GENERAL PURPOSE
Pitch 3.9624mm
Orientation Right Angle
Depth 9.02mm
Current Rating 7A
Voltage - Rated AC 600V
Reliability COMMERCIAL
Approval Agency CSA
Shrouding No
Number of Contacts 9
Mating Information MULTIPLE MATING PARTS AVAILABLE
Body Breadth 0.355 inch
Contact Gender Female
Housing Color Red, White
Rated Current (Signal) 3A
Contact Style SQ PIN-SKT
Contact Resistance 3mOhm
ELV Non-Compliant
Max Voltage Rating (AC) 600V
Polarization Key POLARIZED HOUSING
Wire/Cable Type Discrete
Durability 25 Cycles
Wire/Cable Gauge 22 AWG
Contact Pattern RECTANGULAR
Insertion Force-Max 8.0064 N
Insulation Diameter 2.41 mm
Contact Rating (Current) 7A

Dimensions

Height 9.02mm
Length 35.66mm
Plating Thickness 5.08μm

Compliance

RoHS Status RoHS Compliant
Flammability Rating UL94 V-2
Lead Free Not Applicable
