640427-7
RoHS
/
Package /
Category Connectors, Interconnects / Rectangular Connectors - Free Hanging, Panel Mount
Description
CONN RECEPT 7POS 20AWG MTA156
PDF
/
Inventory: 5786
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Not Applicable
Flammability Rating UL94 V-2
RoHS Status RoHS Compliant
Radiation Hardening No
Dimensions
Plating Thickness 80μm
Length 27.74mm
Height 9.02mm
Technical
Contact Rating (Current) 7A
Insulation Diameter 2.413 mm
Number of Power Positions 7
Wire/Cable Gauge 20 AWG
Wire/Cable Type Discrete
Max Voltage Rating (AC) 600V
ELV Non-Compliant
Contact Resistance 3mOhm
Housing Color Yellow
Contact Gender Female
Number of Contacts 7
Shrouding No
Approval Agency CSA
Voltage - Rated AC 600V
Current Rating 7A
Depth 9.02mm
Orientation Right Angle
Pitch 3.9624mm
Fastening Type Ramp
Gender Female
Number of Rows 1
Color Yellow
Min Operating Temperature -67°C
Max Operating Temperature 221°C
Number of Positions 7
Connector Type Socket
Termination IDC
Packaging Bulk
Physical
Housing Material Nylon
Mount Cable, Free Hanging
Contact Plating Tin
