4-644329-1
RoHS
/
Package /
Category Connectors, Interconnects / Rectangular Connectors - Free Hanging, Panel Mount
Description
Free Hanging Rectangular Connector
PDF
/
Inventory: 7667
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Not Applicable
Flammability Rating UL94 V-0
RoHS Status RoHS Compliant
Dimensions
Plating Thickness 80μin
Technical
Contact Pattern RECTANGULAR
Wire/Cable Gauge 18 AWG
Durability 25 Cycles
Wire/Cable Type Discrete
Dielectric Withstanding Voltage 2200VAC V
Polarization Key POLARIZED HOUSING
ELV Compliant
Insulation Resistance 5000000000Ohm
Contact Resistance 3mOhm
Contact Style SQ PIN-SKT
Body Depth 0.73 inch
UL Flammability Code 94V-0
Operating Temperature (Min) -55°C
Contact Gender Female
Body Breadth 0.355 inch
Number of Contacts 11
Shrouding No
Reliability COMMERCIAL
Reference Standard UL, CSA
Pitch 3.96mm
Option GENERAL PURPOSE
Mixed Contacts NO
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Subcategory Headers and Edge Type Connectors
Fastening Type Ramp
HTS Code 8536.69.40.40
Number of Rows 1
Color Black
Connector Type Connector, Receptacle, Socket
ECCN Code EAR99
Termination IDC
Pbfree Code yes
JESD-609 Code e3
Packaging Bulk
Physical
Housing Material Nylon
Mount Free Hanging
Contact Plating Tin
Contact Material COPPER ALLOY
