3-644382-5
RoHS
/
Package /
Category Connectors, Interconnects / Rectangular Connectors - Free Hanging, Panel Mount
Description
Headers & Wire Housings 05P MTA156 QUAD ASSY W/TB LF
PDF
/
Inventory: 8560
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Contact Material COPPER ALLOY
Contact Plating Tin
Mount Free Hanging
Housing Material Nylon
Technical
Packaging Bulk
JESD-609 Code e3
Pbfree Code yes
Termination IDC
ECCN Code EAR99
Connector Type Connector, Receptacle, Socket
Color Black
Number of Rows 1
Fastening Type Ramp
Subcategory Headers and Edge Type Connectors
Contact Finish - Mating TIN
MIL Conformance NO
DIN Conformance NO
IEC Conformance NO
Filter Feature NO
Mixed Contacts NO
Option GENERAL PURPOSE
Pitch 3.96mm
Reference Standard UL, CSA
Reliability COMMERCIAL
Body Length or Diameter 0.78 inch
Shrouding No
Number of Contacts 5
Contact Gender Female
UL Flammability Code 94V-0
Body Depth 0.73 inch
Rated Current (Signal) 7A
Contact Style SQ PIN-SKT
Contact Resistance 3mOhm
ELV Compliant
Polarization Key POLARIZED HOUSING
Dielectric Withstanding Voltage 2200VAC V
Wire/Cable Type Discrete
Wire/Cable Gauge 20 AWG
Contact Pattern RECTANGULAR
Compliance
RoHS Status RoHS Compliant
Flammability Rating UL94 V-0
Lead Free Not Applicable
