3-644375-6
RoHS
/
Package /
Category Connectors, Interconnects / Rectangular Connectors - Free Hanging, Panel Mount
Description
Headers & Wire Housings 06P MTA156 QUAD ASSY W/O TB L
PDF
/
Inventory: 1415
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Contact Material COPPER ALLOY
Contact Plating Tin
Mount Cable, Free Hanging
Housing Material Nylon
Technical
Packaging Bulk
JESD-609 Code e3
Pbfree Code yes
Termination IDC
ECCN Code EAR99
Connector Type Connector, Receptacle, Socket
Max Operating Temperature 105°C
Min Operating Temperature -55°C
Color Black
Number of Rows 1
Fastening Type Ramp
Subcategory Headers and Edge Type Connectors
MIL Conformance NO
DIN Conformance NO
IEC Conformance NO
Filter Feature NO
Mixed Contacts NO
Option GENERAL PURPOSE
Pitch 3.96mm
Orientation Right Angle
Depth 9.78mm
Reference Standard UL, CSA
Reliability COMMERCIAL
Shrouding No
Number of Contacts 6
Body Breadth 0.385 inch
Contact Gender Female
UL Flammability Code 94V-0
Rated Current (Signal) 7A
Contact Style SQ PIN-SKT
Contact Resistance 3mOhm
Insulation Resistance 5000000000Ohm
ELV Compliant
Max Voltage Rating (AC) 600V
Polarization Key POLARIZED HOUSING
Dielectric Withstanding Voltage 2200VAC V
Wire/Cable Type Discrete
Durability 25 Cycles
Wire/Cable Gauge 18 AWG
Contact Pattern RECTANGULAR
Dimensions
Length 23.77mm
Compliance
RoHS Status RoHS Compliant
Flammability Rating UL94 V-0
Lead Free Not Applicable
