3-644329-7
RoHS
/
Package /
Category Connectors, Interconnects / Rectangular Connectors - Free Hanging, Panel Mount
Description
Rectangular Connector Panel Mount
PDF
/
Inventory: 7763
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Flammability Rating UL94 V-0
RoHS Status RoHS Compliant
Dimensions
Plating Thickness 80μin
Length 27.74mm
Technical
Contact Pattern RECTANGULAR
Wire/Cable Gauge 18 AWG
Durability 25 Cycles
Wire/Cable Type Discrete
Dielectric Withstanding Voltage 2200VAC V
Polarization Key POLARIZED HOUSING
Max Voltage Rating (AC) 600V
Insulation Resistance 5000000000Ohm
Contact Resistance 3mOhm
Contact Style SQ PIN-SKT
UL Flammability Code 94V-0
Contact Gender Female
Body Breadth 0.355 inch
Number of Contacts 7
Shrouding No
Reliability COMMERCIAL
Reference Standard UL, CSA
Depth 9.02mm
Orientation Right Angle
Pitch 3.96mm
Option GENERAL PURPOSE
Mixed Contacts NO
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Subcategory Headers and Edge Type Connectors
Fastening Type Ramp
Number of Rows 1
Color Black
Min Operating Temperature -55°C
Max Operating Temperature 105°C
Connector Type Connector, Receptacle, Socket
Termination IDC
Pbfree Code yes
JESD-609 Code e3
Packaging Bulk
Physical
Housing Material Nylon
Mount Cable, Free Hanging
Contact Plating Tin
Contact Material COPPER ALLOY
