RoHS
/
Package /
Category Connectors, Interconnects / Rectangular Connectors - Free Hanging, Panel Mount
Description Rectangular Connector Panel Mount
PDF
/
Inventory: 2293
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Compliance

Lead Free Not Applicable
Flammability Rating UL94 V-0
RoHS Status RoHS Compliant
Radiation Hardening No

Technical

Contact Design PREASSEM CONN
Insulation Diameter -1.5 mm
Insertion Force-Max 8.0064 N
Contact Pattern RECTANGULAR
Durability 30 Cycles
Wire Gauge (Min) 24 AWG
Wire Gauge (Max) 28 AWG
Wire/Cable Type Discrete
Polarization Key POLARIZED HOUSING
ELV Compliant
Contact Resistance 20mOhm
Contact Style SQ PIN-SKT
Rated Current (Signal) 4A
Body Depth 0.406 inch
UL Flammability Code 94V-0
Number of Contacts 5
Reliability COMMERCIAL
Reference Standard UL
Pitch 2.5mm
Option GENERAL PURPOSE
Mixed Contacts NO
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Contact Finish - Mating TIN
Subcategory Headers and Edge Type Connectors
Gender Female
Number of Rows 1
Color Natural
Connector Type Connector, Receptacle, Socket
ECCN Code EAR99
Termination IDC
Pbfree Code yes
JESD-609 Code e3
Packaging Bulk

Physical

Housing Material Nylon
Mount Free Hanging
Contact Plating Tin
Contact Material Bronze
