RoHS
/
Package /
Category Connectors, Interconnects / Rectangular Connectors - Free Hanging, Panel Mount
Description Rectangular Connector Panel Mount
PDF
/
Inventory: 2724
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Physical

Contact Material Bronze
Contact Plating Tin
Mount Free Hanging
Housing Material Nylon

Technical

Packaging Bulk
JESD-609 Code e3
Pbfree Code yes
Termination IDC
ECCN Code EAR99
Connector Type Connector, Receptacle, Socket
Color Natural
Number of Rows 1
Gender Female
HTS Code 8536.69.40.40
Subcategory Headers and Edge Type Connectors
Contact Finish - Mating TIN
MIL Conformance NO
DIN Conformance NO
IEC Conformance NO
Filter Feature NO
Mixed Contacts NO
Option GENERAL PURPOSE
Pitch 2.5mm
Reference Standard UL
Reliability COMMERCIAL
Number of Contacts 2
UL Flammability Code 94V-0
Body Depth 0.406 inch
Rated Current (Signal) 4A
Contact Style SQ PIN-SKT
ELV Compliant
Polarization Key POLARIZED HOUSING
Wire/Cable Type Discrete
Wire Gauge (Max) 28 AWG
Wire Gauge (Min) 24 AWG
Durability 30 Cycles
Contact Pattern RECTANGULAR
Insulation Diameter -1.5 mm
Contact Design PREASSEM CONN

Compliance

Radiation Hardening No
RoHS Status RoHS Compliant
Flammability Rating UL94 V-0
Lead Free Not Applicable
