2-111196-3
RoHS
/
Package /
Category Connectors, Interconnects / Rectangular Connectors - Free Hanging, Panel Mount
Description
Headers & Wire Housings 72 RCPT SYSTEM 50 LEAD FREE
PDF
/
Inventory: 927
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Contact Material Bronze
Contact Plating Gold, Tin
Mount Free Hanging
Housing Material Thermoplastic
Technical
Packaging Bulk
JESD-609 Code e3
Pbfree Code yes
Termination IDC
ECCN Code EAR99
Connector Type Connector, Receptacle
Max Operating Temperature -105°C
Min Operating Temperature -65°C
Color Black
Number of Rows 2
Voltage - Rated 30V
HTS Code 8536.69.40.40
Fastening Type Latch
Subcategory Headers and Edge Type Connectors
Contact Finish - Mating GOLD (30) OVER NICKEL
MIL Conformance NO
DIN Conformance NO
IEC Conformance NO
Filter Feature NO
Mixed Contacts NO
Option GENERAL PURPOSE
Pitch 1.27mm
Current Rating 500mA
Reference Standard UL
Reliability COMMERCIAL
Row Spacing - Mating 2.54 mm
Number of Contacts 72
Mating Information MULTIPLE MATING PARTS AVAILABLE
Contact Gender Female
UL Flammability Code 94V-0
Body Depth 0.58 inch
Rated Current (Signal) 0.5A
Contact Style IDC
Insulation Resistance 5GOhm
ELV Compliant
Wire/Cable Type Ribbon
Wire Gauge (Max) 32 AWG
Wire Gauge (Min) 30 AWG
Contact Pattern RECTANGULAR
Dimensions
Plating Thickness 30μin
Compliance
Radiation Hardening No
RoHS Status RoHS Compliant
Flammability Rating UL94 V-0
