177534-9
RoHS
/
Package /
Category Connectors, Interconnects / Rectangular Connectors - Free Hanging, Panel Mount
Description
Rectangular Connector Panel Mount
PDF
/
Inventory: 4581
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Contact Material Bronze
Contact Plating Tin
Mount Free Hanging
Housing Material Nylon
Technical
Packaging Bulk
Pbfree Code yes
Termination IDC
Connector Type Connector, Receptacle, Socket
Color Black
Number of Rows 1
Gender Female
Subcategory Headers and Edge Type Connectors
MIL Conformance NO
DIN Conformance NO
IEC Conformance NO
Filter Feature NO
Mixed Contacts NO
Option GENERAL PURPOSE
Pitch 2.5mm
Reference Standard UL
Reliability COMMERCIAL
Number of Contacts 9
Operating Temperature (Min) -25°C
Body Depth 0.406 inch
Rated Current (Signal) 4A
Contact Style SQ PIN-SKT
Contact Resistance 20mOhm
ELV Compliant
Polarization Key POLARIZED HOUSING
Wire/Cable Type Discrete
Wire Gauge (Max) 28 AWG
Wire Gauge (Min) 24 AWG
Durability 30 Cycles
Contact Pattern RECTANGULAR
Insertion Force-Max 6.2272 N
Insulation Diameter -1.5 mm
Contact Design PREASSEM CONN
Compliance
Radiation Hardening No
RoHS Status RoHS Compliant
Flammability Rating UL94 V-0
Lead Free Not Applicable
