1-644511-0
RoHS
/
Package /
Category Connectors, Interconnects / Rectangular Connectors - Free Hanging, Panel Mount
Description
Headers & Wire Housings 10P MTA100 CONN ASSY ON TAPE
PDF
/
Inventory: 9543
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Not Applicable
Flammability Rating UL94 V-2
RoHS Status RoHS Compliant
Dimensions
Plating Thickness 5.08μm
Length 25.4mm
Height 6.99mm
Technical
Contact Rating (Current) 5A
Insulation Diameter 1.52 mm
Contact Pattern RECTANGULAR
Wire/Cable Gauge 22 AWG
Wire/Cable Type Discrete
Polarization Key POLARIZED HOUSING
ELV Non-Compliant
Contact Style SQ PIN-SKT
Rated Current (Signal) 5A
Body Depth 0.52 inch
Housing Color White
UL Flammability Code 94V-2
Contact Gender Female
Body Breadth 0.275 inch
Mating Information MULTIPLE MATING PARTS AVAILABLE
Number of Contacts 10
Shrouding No
Approval Agency CSA
Reliability COMMERCIAL
Voltage - Rated AC 250V
Current Rating 5A
Pitch 2.54mm
Option GENERAL PURPOSE
Mixed Contacts NO
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Subcategory Headers and Edge Type Connectors
Fastening Type Ramp
HTS Code 8536.69.40.40
Number of Rows 1
Color Red
Min Operating Temperature -67°C
Max Operating Temperature 221°C
Connector Type Connector, Receptacle, Socket
ECCN Code EAR99
Termination IDC
Pbfree Code no
JESD-609 Code e0
Packaging Tape & Reel (TR)
Physical
Housing Material Nylon
Mount Free Hanging
Contact Plating Lead, Tin
Contact Material COPPER ALLOY
