1-644471-0
RoHS
/
Package /
Category Connectors, Interconnects / Rectangular Connectors - Free Hanging, Panel Mount
Description
CONN RECEPT 10POS 22AWG MTA156
PDF
/
Inventory: 8873
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Contact Material COPPER ALLOY
Contact Plating Tin
Mount Cable, Free Hanging
Housing Material Nylon
Technical
Packaging Bulk
JESD-609 Code e0
Pbfree Code no
Termination IDC
ECCN Code EAR99
Connector Type Connector, Receptacle, Socket
Max Operating Temperature 221°C
Min Operating Temperature -67°C
Color Red
Number of Rows 1
HTS Code 8536.69.40.40
Subcategory Headers and Edge Type Connectors
MIL Conformance NO
DIN Conformance NO
IEC Conformance NO
Filter Feature NO
Mixed Contacts NO
Option GENERAL PURPOSE
Pitch 3.9624mm
Orientation Right Angle
Current Rating 7A
Voltage - Rated AC 600V
Reliability COMMERCIAL
Approval Agency CSA
Shrouding No
Number of Contacts 10
Body Breadth 0.725 inch
Contact Gender Female
UL Flammability Code 94V-2
Housing Color Red, White
Body Depth 0.385 inch
Contact Style SQ PIN-SKT
Contact Resistance 3mOhm
Body/Shell Style PLUG
ELV Non-Compliant
Max Voltage Rating (AC) 600V
Wire/Cable Type Discrete
Wire/Cable Gauge 22 AWG
Contact Pattern RECTANGULAR
Insulation Diameter 2.41 mm
Contact Rating (Current) 7A
Dimensions
Height 9.779mm
Length 39.62mm
Plating Thickness 5.08μm
Compliance
RoHS Status RoHS Compliant
Flammability Rating UL94 V-2
Lead Free Not Applicable
