1-644043-2
RoHS
/
Package /
Category Connectors, Interconnects / Rectangular Connectors - Free Hanging, Panel Mount
Description
AMP Free Hanging Rectangular Connector
PDF
/
Inventory: 8876
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Contact Material PHOSPHOR BRONZE
Contact Plating Gold
Housing Material Nylon
Mounting Option 1 LOCKING
Technical
JESD-609 Code e0
Pbfree Code no
Termination IDC
ECCN Code EAR99
Connector Type Connector, Receptacle, Socket
Number of Rows 1
Additional Feature AMP
HTS Code 8536.69.40.40
Subcategory Headers and Edge Type Connectors
MIL Conformance NO
DIN Conformance NO
IEC Conformance NO
Filter Feature NO
Mixed Contacts NO
Option GENERAL PURPOSE
Pitch 2.54mm
Reference Standard UL, CSA
Voltage - Rated AC 250V
Reliability COMMERCIAL
Shrouding No
Number of Contacts 12
Mating Information MULTIPLE MATING PARTS AVAILABLE
Body Breadth 0.275 inch
Contact Gender Female
Operating Temperature (Min) -55°C
UL Flammability Code 94V-2
Housing Color White
Body Depth 0.52 inch
Rated Current (Signal) 5A
Contact Style SQ PIN-SKT
Insulation Resistance 5000000000Ohm
ELV Compliant
Polarization Key POLARIZED HOUSING
Dielectric Withstanding Voltage 750VAC V
Durability 25 Cycles
Wire/Cable Gauge 26 AWG
Contact Pattern RECTANGULAR
Insertion Force-Max 8.896 N
Insulator Color BLUE
Compliance
RoHS Status RoHS Compliant
Flammability Rating UL94 V-2
Lead Free Not Applicable
