1-641238-2
RoHS
/
Package /
Category Connectors, Interconnects / Rectangular Connectors - Free Hanging, Panel Mount
Description
Headers & Wire Housings 12P MTA100 CONN ASSY NATL 30AU
PDF
/
Inventory: 4332
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Not Applicable
Flammability Rating UL94 V-2
RoHS Status RoHS Compliant
Dimensions
Width 6.99mm
Length 30.5mm
Height 13.2mm
Technical
Insertion Force-Max 8.896 N
Contact Pattern RECTANGULAR
Wire/Cable Gauge 24 AWG
Durability 25 Cycles
Wire/Cable Type Discrete
Dielectric Withstanding Voltage 750VAC V
Polarization Key POLARIZED HOUSING
ELV Compliant
Insulation Resistance 5000000000Ohm
Contact Style SQ PIN-SKT
Body Depth 0.52 inch
UL Flammability Code 94V-2
Operating Temperature (Min) -55°C
Contact Gender Female
Body Breadth 0.275 inch
Mating Information MULTIPLE MATING PARTS AVAILABLE
Number of Contacts 12
Shrouding No
Reliability COMMERCIAL
Voltage - Rated AC 250V
Reference Standard UL, CSA
Current Rating 5A
Pitch 2.54mm
Option GENERAL PURPOSE
Mixed Contacts NO
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Subcategory Headers and Edge Type Connectors
Fastening Type Ramp
HTS Code 8536.69.40.40
Additional Feature AMP
Number of Rows 1
Color White
Connector Type Connector, Receptacle, Socket
ECCN Code EAR99
Termination IDC
Pbfree Code no
JESD-609 Code e0
Packaging Bulk
Physical
Housing Material Nylon
Mount Free Hanging
Contact Plating Gold
Contact Material COPPER ALLOY
