1-640621-8
RoHS
/
Package /
Category Connectors, Interconnects / Rectangular Connectors - Free Hanging, Panel Mount
Description
Headers & Wire Housings 18P MTA100 CONN ASSY F/T NATL
PDF
/
Inventory: 7601
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Contact Material COPPER ALLOY
Contact Plating Lead, Tin
Mount Free Hanging
Housing Material Nylon
Technical
Packaging Bulk
JESD-609 Code e0
Pbfree Code no
Termination IDC
ECCN Code EAR99
Connector Type Connector, Receptacle, Socket
Max Operating Temperature 221°C
Min Operating Temperature -67°C
Color White
Number of Rows 1
HTS Code 8536.69.40.40
Fastening Type Ramp
Subcategory Headers and Edge Type Connectors
MIL Conformance NO
DIN Conformance NO
IEC Conformance NO
Filter Feature NO
Mixed Contacts NO
Option GENERAL PURPOSE
Pitch 2.54mm
Current Rating 5A
Reference Standard UL
Voltage - Rated AC 250V
Reliability COMMERCIAL
Approval Agency CSA
Shrouding No
Number of Contacts 18
Mating Information MULTIPLE MATING PARTS AVAILABLE
Body Breadth 0.305 inch
Contact Gender Female
UL Flammability Code 94V-2
Body Depth 0.52 inch
Contact Style SQ PIN-SKT
ELV Non-Compliant
Polarization Key POLARIZED HOUSING
Dielectric Withstanding Voltage 750VAC V
Wire/Cable Type Discrete
Durability 25 Cycles
Wire/Cable Gauge 24 AWG
Contact Pattern RECTANGULAR
Insertion Force-Max 8.896 N
Insulation Diameter 1.52 mm
Contact Rating (Current) 5A
Dimensions
Height 7.75mm
Length 45.72mm
Plating Thickness 5.08μm
Compliance
RoHS Status RoHS Compliant
Flammability Rating UL94 V-2
Lead Free Not Applicable
