1-640440-9
RoHS
/
Package /
Category Connectors, Interconnects / Rectangular Connectors - Free Hanging, Panel Mount
Description
Headers & Wire Housings 19P 22AWG MTA100 CON ASSY WHT W/RED STRPE
PDF
/
Inventory: 8276
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Contact Material COPPER ALLOY
Contact Plating Lead, Tin
Mount Free Hanging
Housing Material Nylon
Technical
Packaging Bulk
JESD-609 Code e0
Pbfree Code no
Termination IDC
ECCN Code EAR99
Connector Type Connector, Receptacle, Socket
Max Operating Temperature 221°C
Min Operating Temperature -67°C
Color Red
Number of Rows 1
HTS Code 8536.69.40.40
Fastening Type Ramp
Subcategory Headers and Edge Type Connectors
MIL Conformance NO
DIN Conformance NO
IEC Conformance NO
Filter Feature NO
Mixed Contacts NO
Option GENERAL PURPOSE
Pitch 2.54mm
Current Rating 5A
Voltage - Rated AC 250V
Reliability COMMERCIAL
Approval Agency CSA
Shrouding No
Number of Contacts 19
Mating Information MULTIPLE MATING PARTS AVAILABLE
Body Breadth 0.52 inch
Contact Gender Female
UL Flammability Code 94V-2
Body Depth 0.275 inch
Rated Current (Signal) 4A
Contact Style SQ PIN-SKT
Contact Resistance 5mOhm
Body/Shell Style PLUG
ELV Non-Compliant
Dielectric Withstanding Voltage 750VAC V
Wire/Cable Type Discrete
Wire/Cable Gauge 22 AWG
Contact Pattern RECTANGULAR
Insulation Diameter 1.52 mm
Contact Rating (Current) 5A
Wire Size (Min) 28 AWG
Dimensions
Height 6.99mm
Length 48.26mm
Plating Thickness 2.03μm
Compliance
RoHS Status RoHS Compliant
Flammability Rating UL94 V-2
Lead Free Not Applicable
