1-640429-2
RoHS
/
Package /
Category Connectors, Interconnects / Rectangular Connectors - Free Hanging, Panel Mount
Description
CONN RECEPT 12POS 24AWG MTA156
PDF
/
Inventory: 5992
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Contact Material COPPER ALLOY
Contact Plating Tin
Mount Cable, Free Hanging
Housing Material Nylon
Technical
Packaging Bulk
JESD-609 Code e0
Pbfree Code no
Termination IDC
Connector Type Connector, Receptacle, Socket
Max Operating Temperature 221°C
Min Operating Temperature -67°C
Color White
Number of Rows 1
Fastening Type Ramp
Subcategory Headers and Edge Type Connectors
MIL Conformance NO
DIN Conformance NO
IEC Conformance NO
Filter Feature NO
Mixed Contacts NO
Option GENERAL PURPOSE
Pitch 3.9624mm
Orientation Right Angle
Current Rating 7A
Reference Standard UL
Voltage - Rated AC 600V
Reliability COMMERCIAL
Approval Agency CSA
Shrouding No
Number of Contacts 12
Body Breadth 0.355 inch
Contact Gender Female
UL Flammability Code 94V-2
Body Depth 0.725 inch
Rated Current (Signal) 7A
Contact Style SQ PIN-SKT
Contact Resistance 3mOhm
ELV Non-Compliant
Max Voltage Rating (AC) 600V
Polarization Key POLARIZED HOUSING
Dielectric Withstanding Voltage 2200VAC V
Wire/Cable Type Discrete
Durability 25 Cycles
Wire/Cable Gauge 24 AWG
Contact Pattern RECTANGULAR
Insertion Force-Max 8.0064 N
Withdrawl Force-Min .8896 N
Insulation Diameter 2.41 mm
Contact Rating (Current) 7A
Dimensions
Height 9.02mm
Length 47.55mm
Plating Thickness 5.08μm
Compliance
RoHS Status RoHS Compliant
Flammability Rating UL94 V-2
Lead Free Not Applicable
