1-640426-3 image
Favorite
1-640426-3 image
Favorite
RoHS
/
Package /
Category Connectors, Interconnects / Rectangular Connectors - Free Hanging, Panel Mount
Description Headers & Wire Housings MTA 156 CONN 18-13P
PDF
/
Inventory: 9592
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Compliance

Lead Free Not Applicable
Flammability Rating UL94 V-2
RoHS Status Non-RoHS Compliant

Dimensions

Plating Thickness 80μm
Length 51.5112mm
Height 9.02mm

Technical

Contact Rating (Current) 7A
Insulation Diameter 2.413 mm
Withdrawl Force-Min .8896 N
Insertion Force-Max 8.0064 N
Contact Pattern RECTANGULAR
Wire/Cable Gauge 18 AWG
Durability 25 Cycles
Wire/Cable Type Discrete
Dielectric Withstanding Voltage 2200VAC V
Polarization Key POLARIZED HOUSING
Max Voltage Rating (AC) 600V
ELV Non-Compliant
Contact Resistance 3mOhm
Contact Style SQ PIN-SKT
Rated Current (Signal) 7A
UL Flammability Code 94V-2
Contact Gender Female
Body Breadth 0.355 inch
Shrouding No
Approval Agency CSA
Reliability COMMERCIAL
Voltage - Rated AC 600V
Current Rating 7A
Depth 9.02mm
Orientation Right Angle
Total Number of Contacts 13
Pitch 3.96mm
Option GENERAL PURPOSE
Mixed Contacts NO
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Subcategory Headers and Edge Type Connectors
Fastening Type Ramp
HTS Code 8536.69.40.40
Gender Receptacle
Number of Rows 1
Color Orange
Min Operating Temperature -67°C
Max Operating Temperature 221°C
Number of Positions 13
Connector Type Socket
ECCN Code EAR99
Termination IDC, IDT
Pbfree Code no
JESD-609 Code e0
Packaging Bulk

Physical

Housing Material Nylon
Mount Cable, Free Hanging
Contact Plating Tin
Contact Material COPPER ALLOY
