1-111446-9
RoHS
/
Package /
Category Connectors, Interconnects / Rectangular Connectors - Free Hanging, Panel Mount
Description
CONN IDC PIN 24POS 30AU NO LATCH
PDF
/
Inventory: 2647
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Contact Material Bronze
Contact Plating Tin
Mount Free Hanging
Housing Material Thermoplastic
Technical
Pbfree Code yes
Termination IDC
ECCN Code EAR99
Connector Type Connector, Pin, Plug
Max Operating Temperature -105°C
Min Operating Temperature -65°C
Color Black
Number of Rows 2
HTS Code 8536.69.40.30
Contact Finish - Mating NOT SPECIFIED
MIL Conformance NO
DIN Conformance NO
IEC Conformance NO
Option GENERAL PURPOSE
Pitch 2.54mm
Orientation Vertical
Current Rating 1A
Approval Agency CSA, UL
Row Spacing - Mating 2.54 mm
Number of Contacts 24
Contact Gender Male
ELV Compliant
Wire/Cable Type Ribbon
Wire Gauge (Max) 28 AWG
Wire Gauge (Min) 26 AWG
Insulation Diameter -970 μm
Mating Post Length 6.1mm
Dimensions
Length 45.01mm
Width 8.38mm
Plating Thickness 762 nm
Compliance
RoHS Status RoHS Compliant
Flammability Rating UL94 V-0
Lead Free Lead Free
