644860-8
RoHS
/
Package /
Category Connectors, Interconnects / Rectangular Connectors - Free Hanging, Panel Mount
Description
Headers & Wire Housings 08P MTA156 CONN ASSY 18AWG BLK
PDF
/
Inventory: 8191
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Not Applicable
Flammability Rating UL94 V-0
RoHS Status RoHS Compliant
Dimensions
Plating Thickness 5.08μm
Length 31.75mm
Height 9.144mm
Technical
Contact Rating (Current) 7A
Insulation Diameter 2.41 mm
Wire/Cable Gauge 18 AWG
Max Voltage Rating (AC) 600V
ELV Non-Compliant
Contact Resistance 3mOhm
Housing Color Black
UL Flammability Code 94V-0
Contact Gender Female
Mating Information MULTIPLE MATING PARTS AVAILABLE
Number of Contacts 8
Shrouding No
Approval Agency CSA
Voltage - Rated AC 600V
Current Rating 7A
Depth 9.02mm
Orientation Right Angle
Pitch 3.9624mm
Option GENERAL PURPOSE
Mixed Contacts NO
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Number of Rows 1
Min Operating Temperature -67°C
Max Operating Temperature 221°C
Connector Type Connector, Receptacle, Socket
Termination IDC
Pbfree Code no
JESD-609 Code e0
Physical
Housing Material Nylon
Mount Cable
Contact Plating Lead, Tin
Contact Material COPPER ALLOY
