1-640602-0
RoHS
/
Package /
Category Connectors, Interconnects / Rectangular Connectors - Free Hanging, Panel Mount
Description
CONN RECEPT 10POS 24AWG MTA156
PDF
/
Inventory: 5247
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Contact Material COPPER ALLOY
Contact Plating Tin
Mount Free Hanging
Housing Material Nylon
Technical
Packaging Bulk
JESD-609 Code e0
Pbfree Code no
Termination IDC
ECCN Code EAR99
Connector Type Socket
Number of Positions 10
Max Operating Temperature 221°C
Min Operating Temperature -67°C
Color White
Number of Rows 1
HTS Code 8536.69.40.40
Fastening Type Ramp
Subcategory Headers and Edge Type Connectors
MIL Conformance NO
DIN Conformance NO
IEC Conformance NO
Filter Feature NO
Mixed Contacts NO
Option GENERAL PURPOSE
Pitch 3.9624mm
Total Number of Contacts 10
Current Rating 7A
Reference Standard UL
Voltage - Rated AC 600V
Reliability COMMERCIAL
Approval Agency CSA
Shrouding No
Body Breadth 0.385 inch
Contact Gender Female
UL Flammability Code 94V-2
Body Depth 0.725 inch
Rated Current (Signal) 7A
Contact Style SQ PIN-SKT
Contact Resistance 5mOhm
Body/Shell Style RECEPTACLE
ELV Non-Compliant
Polarization Key POLARIZED HOUSING
Dielectric Withstanding Voltage 2200VAC V
Wire/Cable Type Discrete
Durability 25 Cycles
Wire/Cable Gauge 24 AWG
Contact Pattern RECTANGULAR
Insertion Force-Max 8.0064 N
Withdrawl Force-Min .8896 N
Insulation Diameter 2.413 mm
Contact Rating (Current) 7A
Dimensions
Height 9.78mm
Length 39.62mm
Plating Thickness 80μm
Compliance
RoHS Status RoHS Compliant
Flammability Rating UL94 V-2
Lead Free Not Applicable
