1-640433-9
RoHS
/
Package /
Category Connectors, Interconnects / Rectangular Connectors - Free Hanging, Panel Mount
Description
Headers & Wire Housings 19P MTA156 CONN ASSY 22AWG RED
PDF
/
Inventory: 1610
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Not Applicable
Flammability Rating UL94 V-2
RoHS Status RoHS Compliant
Dimensions
Plating Thickness 5.08μm
Length 75.29mm
Height 9.02mm
Technical
Contact Rating (Current) 7A
Insulation Diameter 2.41 mm
Withdrawl Force-Min .8896 N
Insertion Force-Max 8.0064 N
Contact Pattern RECTANGULAR
Wire/Cable Gauge 22 AWG
Durability 25 Cycles
Wire/Cable Type Discrete
Polarization Key POLARIZED HOUSING
Max Voltage Rating (AC) 600V
ELV Non-Compliant
Contact Resistance 3mOhm
Contact Style SQ PIN-SKT
Rated Current (Signal) 3A
Housing Color White
UL Flammability Code 94V-2
Contact Gender Female
Body Breadth 0.355 inch
Mating Information MULTIPLE MATING PARTS AVAILABLE
Number of Contacts 19
Shrouding No
Approval Agency CSA
Reliability COMMERCIAL
Voltage - Rated AC 600V
Current Rating 7A
Depth 9.02mm
Orientation Right Angle
Pitch 3.9624mm
Option GENERAL PURPOSE
Mixed Contacts NO
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Subcategory Headers and Edge Type Connectors
HTS Code 8536.69.40.40
Number of Rows 1
Color Red
Min Operating Temperature -67°C
Max Operating Temperature 221°C
Connector Type Connector, Receptacle, Socket
ECCN Code EAR99
Termination IDC
Pbfree Code no
JESD-609 Code e0
Published 2008
Packaging Bulk
Physical
Housing Material Nylon
Mount Free Hanging
Contact Plating Lead, Tin
Contact Material COPPER ALLOY
Supply Chain
Factory Lead Time 17 Weeks
