1-530758-0

TE Connectivity
RoHS
/
Package /
Category Connectors, Interconnects / Rectangular Connectors - Free Hanging, Panel Mount
Description Rectangular Connector Panel Mount
PDF
/
Inventory: 2506
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Compliance

RoHS Status Non-RoHS Compliant
Radiation Hardening No

Dimensions

Plating Thickness 50μin

Technical

Contact Design PREASSEM CONN
Mating Contact Row Spacing 0.1 inch
Contact Pattern RECTANGULAR
Polarization Key ENDS
Contact Style SQ PIN-SKT
Body Depth 0.4 inch
Lead Length 5.59mm
Contact Gender FEMALE
Mating Information MULTIPLE MATING PARTS AVAILABLE
Number of Contacts 120
Body Length or Diameter 6.855 inch
Reliability COMMERCIAL
Orientation Vertical
Pitch 2.54mm
Option GENERAL PURPOSE
Mixed Contacts NO
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance YES
Subcategory Headers and Edge Type Connectors
Number of Rows 2
Color Blue
Connector Type Connector, Receptacle, Socket
Termination Solder
Packaging Bulk

Physical

Mount Panel
Contact Plating Gold
Contact Material Copper
