XN2A-1870
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Rectangular Connectors - Free Hanging, Panel Mount
Description
CONN PLUG 8POS IDC 20-28AWG GOLD
PDF
/
Buying Options
Total Price: USD $9.8
Unit Price: USD $9.8032
≥1 USD $9.8032
≥10 USD $9.67032
≥100 USD $9.53744
≥500 USD $9.404947
≥1000 USD $9.272507
≥3000 USD $8.477726
Inventory: 140
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status RoHS Compliant
Dimensions
Contact Finish Thickness 8.00μin 0.203μm
Technical
Wire Type Discrete
Cable Termination Spring Clamp
Max Voltage Rating (DC) 32V
Durability 50 Cycles
Wire Gauge (Min) 20 AWG
Wire Gauge (Max) 28 AWG
Wire Gauge 20-28 AWG
Contact Resistance 30mOhm
Body Depth 0.709 inch
UL Flammability Code 94V-0
Body Breadth 0.236 inch
Body Length or Diameter 0.937 inch
Reliability COMMERCIAL
Contact Finish Gold
Reference Standard UL
Current Rating 3A
Orientation Straight
Total Number of Contacts 8
Pitch 0.079 2.00mm
Option GENERAL PURPOSE
Mixed Contacts NO
Contact Type Male Pin
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Voltage - Rated DC 32V
Subcategory Headers and Edge Type Connectors
Fastening Type Latch Lock
Gender Male
Number of Rows 1
Color Black
Min Operating Temperature -30°C
Max Operating Temperature 75°C
Number of Positions 8
Connector Type Plug
ECCN Code EAR99
Termination IDT
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
JESD-609 Code e3
Series XN2
Published 2001
Packaging Bulk
Physical
Insulation Material POLYBUTYLENE TEREPHTHALATE
Mounting Type Free Hanging (In-Line)
Mount Cable, Free Hanging
Contact Material Bronze, Gold
Supply Chain
Factory Lead Time 7 Weeks
