XG5M-1032-N
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Rectangular Connectors - Free Hanging, Panel Mount
Description
Socket Header PCB - Vertical 10P
PDF
/
Buying Options
Total Price: USD $2.6
Unit Price: USD $2.6048
≥1 USD $2.6048
≥10 USD $2.3628
≥100 USD $2.238368
≥500 USD $2.18614
≥1000 USD $2.08208
≥3000 USD $1.83282
Inventory: 1165
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status RoHS Compliant
Radiation Hardening No
Dimensions
Plating Thickness 6μin
Contact Finish Thickness 5.90μin 0.150μm
Length 17.3mm
Technical
Contact Design PREASSEM CONN
Wire Type Discrete
Insertion Force-Max 1.946 N
Cable Termination IDC
Wire/Cable Gauge 24 AWG
Dielectric Withstanding Voltage 650VAC V
Max Current Rating 3A
Termination Type IDC
Max Voltage Rating (AC) 300V
Row Spacing 0.100 (2.54mm)
Wire Gauge 24 AWG
Rated Current (Signal) 3A
UL Flammability Code 94V-0
Reliability COMMERCIAL
Contact Finish Gold
Reference Standard UL
Current Rating 3A
Depth 14.4mm
Orientation Straight
Total Number of Contacts 10
Pitch 0.100 2.54mm
Option GENERAL PURPOSE
Mixed Contacts NO
Contact Type Female Socket
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Subcategory D Type Connectors
Additional Feature POLARISED
Voltage - Rated 300V
Number of Rows 2
Color Black
Min Operating Temperature -55°C
Max Operating Temperature 85°C
Number of Positions 10
Connector Type Receptacle
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Feature Closed End, Polarizing Key
Series XG5
Published 2002
Packaging Tray
Physical
Housing Material Polybutylene
Mounting Type Free Hanging (In-Line)
Mount Free Hanging
Contact Material Bronze
Supply Chain
Factory Lead Time 16 Weeks
