XG4E-2032
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Rectangular Connectors - Free Hanging, Panel Mount
Description
Headers & Wire Housings ShortLock Plug 20Pin OpenCover 1Polarize
PDF
/
Buying Options
Total Price: USD $4.55
Unit Price: USD $4.5496
≥1 USD $4.5496
≥10 USD $4.11488
≥100 USD $3.887488
≥500 USD $3.792677
≥1000 USD $3.603037
≥3000 USD $3.338597
Inventory: 933
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 12 Weeks
Physical
Contact Material PHOSPHOR BRONZE
Mount Cable, Free Hanging
Mounting Type Free Hanging (In-Line)
Housing Material PBT
Technical
Packaging Bulk
Published 2002
Series XG4
JESD-609 Code e3
Feature Feed Through
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination IDT
ECCN Code EAR99
Connector Type Plug
Number of Positions 20
Max Operating Temperature 105°C
Min Operating Temperature -55°C
Color Black
Number of Rows 2
Voltage - Rated 250V
HTS Code 8536.69.40.40
Fastening Type Latch Lock/Eject Hooks, Short
Contact Type Male Pin
Pitch 0.100 2.54mm
Orientation Right Angle
Current Rating 1A
Contact Finish Gold
Contact Gender Male
Contact Resistance 20mOhm
Insulation Resistance 1GOhm
Row Spacing 0.100 (2.54mm)
Max Voltage Rating (AC) 250V
Max Current Rating 1A
Wire/Cable Type Ribbon
Cable Termination IDC
Wire Type Ribbon Cable
Dimensions
Contact Finish Thickness 5.90μin 0.150μm
Compliance
Radiation Hardening No
RoHS Status RoHS Compliant
