87568-2491
RoHS
/
Package /
Category Connectors, Interconnects / Rectangular Connectors - Free Hanging, Panel Mount
Description
CONN RECEPT 24POS 2MM IDT GOLD
PDF
/
Inventory: 3886
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Contact Material NOT SPECIFIED
Contact Plating Gold
Mount Cable, Free Hanging
Housing Material Plastic
Technical
Published 2005
Part Status Discontinued
Termination IDT
Connector Type IDC, Receptacle, Socket
Number of Positions 24
Max Operating Temperature 85°C
Min Operating Temperature -20°C
Color Black
Number of Rows 2
Additional Feature POLARISED
Fastening Type Ramp
Subcategory Headers and Edge Type Connectors
Contact Finish - Mating NOT SPECIFIED
MIL Conformance NO
DIN Conformance NO
IEC Conformance NO
Filter Feature NO
Mixed Contacts NO
Option GENERAL PURPOSE
Pitch 2.0066mm
Total Number of Contacts 24
Orientation Right Angle
Reach Compliance Code unknown
Reference Standard UL
Reliability COMMERCIAL
Row Spacing - Mating 2.0066 mm
Mating Information MULTIPLE MATING PARTS AVAILABLE
Contact Gender FEMALE
UL Flammability Code 94V-0
Body Depth 0.449 inch
Rated Current (Signal) 1A
Contact Style SQ PIN-SKT
Contact Resistance 30mOhm
Insulation Resistance 5000000000Ohm
Polarization Key POLARIZED KEY
Dielectric Withstanding Voltage 500VAC V
Wire/Cable Type Ribbon
Durability 600 Cycles
Wire/Cable Gauge 28 AWG
Contact Pattern RECTANGULAR
Insertion Force-Max 1.946 N
Contact Design PREASSEM CONN
Glow Wire Compliant Non-compliant
Dimensions
Plating Thickness 15μin
Compliance
RoHS Status RoHS Compliant
Lead Free Contains Lead
