87568-2461
RoHS
/
Package /
Category Connectors, Interconnects / Rectangular Connectors - Free Hanging, Panel Mount
Description
MILLI-GRID POLARIZED Rectangular Connector Panel Mount
PDF
/
Inventory: 6833
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Contains Lead
RoHS Status Non-RoHS Compliant
Dimensions
Plating Thickness 15μin
Technical
Glow Wire Compliant Non-compliant
Contact Design PREASSEM CONN
Insertion Force-Max 1.946 N
Contact Pattern RECTANGULAR
Wire/Cable Gauge 28 AWG
Durability 600 Cycles
Wire/Cable Type Ribbon
Dielectric Withstanding Voltage 500VAC V
Insulation Resistance 5000000000Ohm
Contact Resistance 30mOhm
Contact Style SQ PIN-SKT
Rated Current (Signal) 1A
Body Depth 0.449 inch
UL Flammability Code 94V-0
Mating Information MULTIPLE MATING PARTS AVAILABLE
Row Spacing - Mating 2.0066 mm
Reliability COMMERCIAL
Reference Standard UL
Reach Compliance Code unknown
Orientation Right Angle
Total Number of Contacts 24
Pitch 2.0066mm
Option GENERAL PURPOSE
Mixed Contacts NO
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Contact Finish - Mating NOT SPECIFIED
Subcategory Headers and Edge Type Connectors
HTS Code 8536.69.40.40
Additional Feature MILLI-GRID, POLARIZED
Gender Receptacle
Number of Rows 2
Color Black
Min Operating Temperature -20°C
Max Operating Temperature 85°C
Number of Positions 24
Connector Type IDC, Receptacle, Socket
ECCN Code EAR99
Termination IDT
Physical
Housing Material Plastic
Mount Cable, Free Hanging
Contact Plating Gold
Contact Material NOT SPECIFIED
