52478-6015
RoHS
/
Package /
Category Connectors, Interconnects / Rectangular Connectors - Free Hanging, Panel Mount
Description
CONN RECEPT IDT 60POS 2MM
PDF
/
Inventory: 5777
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Lead Free
RoHS Status RoHS Compliant
Dimensions
Plating Thickness 35μin
Technical
Insulation Diameter-Min 0.033 inch
Glow Wire Compliant Non-compliant
Withdrawl Force-Min .5004 N
Contact Pattern RECTANGULAR
Durability 30 Cycles
Wire Gauge (Min) 26 AWG
Wire Gauge (Max) 28 AWG
Wire/Cable Type Discrete
Dielectric Withstanding Voltage 500VAC V
Polarization Key POLARIZED HOUSING
Termination Type IDC
Insulation Resistance 1000000000Ohm
Contact Style SQ PIN-SKT
UL Flammability Code 94V-0
Operating Temperature (Min) -40°C
Contact Gender Female
Operating Temperature (Max) 105°C
Row Spacing - Mating 2.4892 mm
Reliability COMMERCIAL
Reference Standard UL
Current Rating 1.5A
Reach Compliance Code unknown
Total Number of Contacts 60
Pitch 2.0066mm
Option GENERAL PURPOSE
Mixed Contacts NO
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Contact Finish - Mating NOT SPECIFIED
Subcategory Headers and Edge Type Connectors
HTS Code 8536.69.40.40
Additional Feature BAG PACKAGING
Voltage - Rated 125V
Number of Rows 2
Color Grey
Number of Positions 60
Connector Type IDC, Receptacle, Socket
ECCN Code EAR99
Physical
Housing Material Plastic
Mount Free Hanging
Contact Plating Tin
Contact Material Bronze
