52478-1815
RoHS
/
Package /
Category Connectors, Interconnects / Rectangular Connectors - Free Hanging, Panel Mount
Description
CONN RECEPT IDT 18POS 2MM
PDF
/
Inventory: 7632
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Contact Material Bronze
Contact Plating Tin
Mount Free Hanging
Housing Material Plastic
Technical
Published 2001
Part Status Discontinued
ECCN Code EAR99
Connector Type IDC, Receptacle, Socket
Number of Positions 18
Color Grey
Number of Rows 2
Voltage - Rated 125V
Additional Feature BAG PACKAGING
HTS Code 8536.69.40.40
Subcategory Headers and Edge Type Connectors
Contact Finish - Mating NOT SPECIFIED
MIL Conformance NO
DIN Conformance NO
IEC Conformance NO
Filter Feature NO
Mixed Contacts NO
Option GENERAL PURPOSE
Pitch 2.0066mm
Total Number of Contacts 18
Reach Compliance Code unknown
Current Rating 1.5A
Reference Standard UL
Reliability COMMERCIAL
Body Length or Diameter 0.846 inch
Row Spacing - Mating 2.4892 mm
Operating Temperature (Max) 105°C
Contact Gender Female
Operating Temperature (Min) -40°C
UL Flammability Code 94V-0
Contact Style SQ PIN-SKT
Insulation Resistance 1000000000Ohm
Termination Type IDC
Polarization Key POLARIZED HOUSING
Dielectric Withstanding Voltage 500VAC V
Wire/Cable Type Discrete
Wire Gauge (Max) 28 AWG
Wire Gauge (Min) 26 AWG
Durability 30 Cycles
Contact Pattern RECTANGULAR
Insertion Force-Max 3.4194 N
Glow Wire Compliant Non-compliant
Insulation Diameter-Min 0.033 inch
Dimensions
Plating Thickness 35μin
Compliance
RoHS Status RoHS Compliant
Lead Free Lead Free
