14-60-0222
RoHS
/
Package /
Category Connectors, Interconnects / Rectangular Connectors - Free Hanging, Panel Mount
Description
Headers & Wire Housings CGrid SL IDT Opt G TIN 22Ckt
PDF
/
Inventory: 5620
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Lead Free
RoHS Status RoHS Compliant
Dimensions
Width 2.51mm
Length 55.9mm
Height 15.2mm
Technical
Glow Wire Compliant Non-compliant
Contact Pattern RECTANGULAR
Wire/Cable Gauge 24 AWG
Durability 25 Cycles
Wire/Cable Type Discrete
Polarization Key POLARIZED HOUSING
Body/Shell Style PLUG
Contact Resistance 30mOhm
Contact Style SQ PIN-SKT
Rated Current (Signal) 3A
Body Depth 0.6 inch
UL Flammability Code 94V-0
Operating Temperature (Min) -40°C
Contact Gender Female
Reliability COMMERCIAL
Reference Standard UL, CSA
Current Rating 3A
Reach Compliance Code unknown
Total Number of Contacts 22
Pitch 2.54mm
Option GENERAL PURPOSE
Mixed Contacts NO
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Subcategory Headers and Edge Type Connectors
Fastening Type Latch
Additional Feature SL
Voltage - Rated 250V
Number of Rows 1
Color Black
Number of Positions 22
Connector Type IDC, Receptacle, Socket
Termination IDC
Part Status Active
Pbfree Code yes
JESD-609 Code e3
Published 2010
Physical
Housing Material Polyester
Mount Free Hanging
Contact Plating Tin
Contact Material Bronze
Supply Chain
Factory Lead Time 6 Weeks
