14-60-0041
RoHS
/
Package /
Category Connectors, Interconnects / Rectangular Connectors - Free Hanging, Panel Mount
Description
Headers & Wire Housings SL IDT Opt A Female 24AWG Tin 4Ckt
PDF
/
Inventory: 7724
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Lead Free
RoHS Status RoHS Compliant
Technical
Glow Wire Compliant Non-compliant
Contact Pattern RECTANGULAR
Max Voltage Rating (DC) 250.25kV
Wire/Cable Gauge 24 AWG
Durability 25 Cycles
Wire/Cable Type Discrete
Polarization Key POLARIZED HOUSING
Body/Shell Style PLUG
Contact Resistance 15mOhm
Contact Style SQ PIN-SKT
Rated Current (Signal) 3A
Body Depth 0.6 inch
Contact Gender Female
Body Breadth 0.099 inch
Body Length or Diameter 0.399 inch
Reliability COMMERCIAL
Reference Standard UL, CSA
Current Rating 3A
Orientation Straight
Total Number of Contacts 4
Pitch 2.54mm
Option GENERAL PURPOSE
Mixed Contacts NO
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Contact Finish - Mating SN-PB ON NI
Subcategory Headers and Edge Type Connectors
Additional Feature SL
Voltage - Rated 250V
Number of Rows 1
Color Black
Min Operating Temperature -40°C
Max Operating Temperature 105°C
Number of Positions 4
Connector Type IDC, Receptacle, Socket
ECCN Code EAR99
Termination IDT
Part Status Active
Pbfree Code yes
Published 2010
Physical
Housing Material Polyester
Mount Cable, Free Hanging
Contact Plating Tin
Contact Material Bronze
Supply Chain
Factory Lead Time 6 Weeks
