14-56-2251

Molex
RoHS
/
Package /
Category Connectors, Interconnects / Rectangular Connectors - Free Hanging, Panel Mount
Description Headers & Wire Housings CGrid SL IDT Conn Opt A 15SAu 25Ckt
PDF
/
Inventory: 9656
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Compliance

Lead Free Lead Free
RoHS Status RoHS Compliant

Dimensions

Width 2.51mm
Length 63.5mm
Height 15.2mm

Technical

Glow Wire Compliant Non-compliant
Insertion Force-Max 2.224 N
Contact Pattern RECTANGULAR
Wire/Cable Gauge 24 AWG
Wire/Cable Type Discrete
Body/Shell Style PLUG
Contact Resistance 30mOhm
Contact Style SQ PIN-SKT
Rated Current (Signal) 3A
UL Flammability Code 94V-0
Operating Temperature (Min) -40°C
Contact Gender Female
Body Breadth 0.099 inch
Mating Information MULTIPLE MATING PARTS AVAILABLE
Reliability COMMERCIAL
Reference Standard UL
Current Rating 3A
Reach Compliance Code unknown
Total Number of Contacts 25
Pitch 2.54mm
Option GENERAL PURPOSE
Mixed Contacts NO
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Contact Finish - Mating AU
Subcategory Headers and Edge Type Connectors
HTS Code 8536.69.40.40
Additional Feature STACKED
Voltage - Rated 250V
Number of Rows 1
Color Black
Number of Positions 25
Connector Type IDC, Receptacle, Socket
ECCN Code EAR99
Termination IDC
Part Status Active
Pbfree Code yes
Published 2010

Physical

Housing Material Polyester
Mount Free Hanging
Contact Plating Gold
Contact Material Bronze

Supply Chain

Factory Lead Time 6 Weeks
