14-56-2022
RoHS
/
Package /
Category Connectors, Interconnects / Rectangular Connectors - Free Hanging, Panel Mount
Description
Headers & Wire Housings CGrid SL IDT Opt G 15 SAu 2Ckt
PDF
/
Buying Options
Total Price: USD $0.68
Unit Price: USD $0.679869
≥1 USD $0.679869
≥10 USD $0.641388
≥100 USD $0.605085
≥500 USD $0.57083
≥1000 USD $0.538523
Inventory: 6398
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status RoHS Compliant
Radiation Hardening No
Dimensions
Length 5.05mm
Height 14.1mm
Technical
Glow Wire Compliant Non-compliant
Current Rating (Max) 6A
Contact Pattern RECTANGULAR
Max Voltage Rating (DC) 250.25kV
Wire/Cable Gauge 24 AWG
Wire/Cable Type Discrete
Polarization Key POLARIZED HOUSING
Max Voltage Rating (AC) 250V
Body/Shell Style PLUG
Contact Resistance 15mOhm
Contact Style SQ PIN-SKT
UL Flammability Code 94V-0
Contact Gender Female
Mating Information MULTIPLE MATING PARTS AVAILABLE
Number of Contacts 2
Reliability COMMERCIAL
Reference Standard UL
Current Rating 3A
Depth 15.24mm
Orientation Straight
Pitch 2.54mm
Option GENERAL PURPOSE
Mixed Contacts NO
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Subcategory Headers and Edge Type Connectors
Fastening Type Latch
HTS Code 8536.69.40.40
Additional Feature STACKABLE
Voltage - Rated 250V
Gender Receptacle
Number of Rows 1
Color Black
Min Operating Temperature -40°C
Max Operating Temperature 105°C
Connector Type IDC, Receptacle, Socket
ECCN Code EAR99
Termination IDT
Pbfree Code yes
Physical
Housing Material Polyester
Mount Cable, Free Hanging, Through Hole
Contact Plating Gold
Contact Material Brass, Bronze
