0014564161
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Rectangular Connectors - Free Hanging, Panel Mount
Description
Headers & Wire Housings CGrid SL IDT OPT D 30 SAu 16Ckt
PDF
/
Inventory: 7246
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Contact Finish Thickness 30.0μin 0.76μm
Length 40.61mm
Technical
Wire Type Discrete or Ribbon Cable
Cable Termination IDC
Wire/Cable Gauge 24 AWG
Wire/Cable Type Discrete
Max Voltage Rating (AC) 250V
Wire Gauge 24 AWG
Contact Resistance 15mOhm
UL Flammability Code 94V-0
Mating Information MULTIPLE MATING PARTS AVAILABLE
Number of Contacts 16
Contact Finish Gold
Current Rating 3A
Reach Compliance Code unknown
Depth 15.24mm
Orientation Straight
Pitch 0.100 2.54mm
Option GENERAL PURPOSE
Mixed Contacts NO
Contact Type Female Socket
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Additional Feature POLARIZED
Gender Female
Number of Rows 1
Color Black
Min Operating Temperature -40°C
Max Operating Temperature 105°C
Connector Type Receptacle
Termination IDT
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Feature Closed End
JESD-609 Code e3
Series SL 70400
Packaging Tube
Physical
Housing Material Polyester
Mounting Type Free Hanging (In-Line)
Mount Free Hanging
Contact Material Bronze
Supply Chain
Factory Lead Time 5 Weeks
