MTB1-17PS
RoHS
/
Package /
Category Connectors, Interconnects / Rectangular Connectors - Free Hanging, Panel Mount
Description
PANEL MOUNTABLE Free Hanging Rectangular Connector
PDF
/
Inventory: 3254
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Dimensions
Plating Thickness 50μin
Contact Finish Thickness 50.0μin 1.27μm
Technical
Wire Type Discrete
Insertion Force-Max 2.224 N
Cable Termination Solder
Durability 500 Cycles
Body/Shell Style PLUG
Insulation Resistance 5000000000Ohm
Wire Gauge 24-32 AWG
Contact Resistance 8mOhm
Rated Current (Signal) 3A
Body Depth 0.408 inch
Operating Temperature (Min) -55°C
Body Breadth 0.08 inch
Mating Information MULTIPLE MATING PARTS AVAILABLE
Body Length or Diameter 0.87 inch
Contact Finish Gold
Reach Compliance Code compliant
Total Number of Contacts 17
Pitch 0.050 1.27mm
Option GENERAL PURPOSE
Mixed Contacts NO
Contact Type Male Pin
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Subcategory Headers and Edge Type Connectors
Fastening Type Push-Pull
HTS Code 8536.69.40.40
Additional Feature PANEL MOUNTABLE
Number of Rows 1
Number of Positions 17
Connector Type BOARD CONNECTOR
ECCN Code EAR99
Part Status Active
JESD-609 Code e4
Series MTB
Published 2006
Packaging Bulk
Physical
Mounting Option 1 LOCKING
Insulation Material GLASS FILLED DIALLYL PHTHALATE
Mounting Type Free Hanging (In-Line)
Contact Material COPPER ALLOY
Supply Chain
Factory Lead Time 7 Weeks
