HIF6-50D-1.27R(02)
RoHS
/
Package /
Category Connectors, Interconnects / Rectangular Connectors - Free Hanging, Panel Mount
Description
CONN RCPT 50POS IDC 28AWG GOLD
PDF
/
Inventory: 6293
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status RoHS Compliant
Technical
Insulation Diameter-Min 0.031 inch
Contact Design PREASSEM CONN
Wire Type Ribbon Cable
Cable Termination IDC
Wire/Cable Gauge 28 AWG
Wire/Cable Type Ribbon
Dielectric Withstanding Voltage 300VAC V
Polarization Key POLARIZED HOUSING
Termination Type IDC
Row Spacing 0.100 (2.54mm)
Insulation Resistance 1000000000Ohm
Wire Gauge 28 AWG
Contact Resistance 30mOhm
Rated Current (Signal) 0.5A
Operating Temperature (Min) -55°C
Operating Temperature (Max) 85°C
Body Length or Diameter 1.48 inch
Reliability COMMERCIAL
Contact Finish Gold
Reference Standard UL
Current Rating 500mA
Reach Compliance Code unknown
Total Number of Contacts 50
Pitch 0.050 1.27mm
Contact Type Female Socket
Subcategory Headers and Edge Type Connectors
Voltage - Rated 125V
Number of Rows 2
Color Black
Number of Positions 50
Connector Type Receptacle
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Feature Feed Through, Strain Relief
Series HIF6
Packaging Bulk
Physical
Insulation Material POLYBUTYLENE TEREPHTHALATE
Mounting Type Free Hanging (In-Line)
Mount Free Hanging
Contact Material COPPER ALLOY
