DF36C-15P-0.4SD

Hirose
RoHS
/
Package /
Category Connectors, Interconnects / Rectangular Connectors - Free Hanging, Panel Mount
Description Rectangular Connector Panel Mount
PDF
/
Inventory: 5543
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Compliance

RoHS Status RoHS Compliant

Technical

Contact Pattern RECTANGULAR
Durability 30 Cycles
Wire Gauge (Min) 42 AWG
Wire Gauge (Max) 46 AWG
Wire/Cable Type Discrete
Termination Type SURFACE MOUNT
Insulation Resistance 50000000Ohm
Contact Resistance 80mOhm
Contact Style SQ PIN-SKT
Body Depth 0.059 inch
Operating Temperature (Min) -35°C
Operating Temperature (Max) 85°C
PCB Contact Pattern RECTANGULAR
Number Of PCB Rows 1
Reliability COMMERCIAL
Reference Standard UL
Number of Conductors ONE
Reach Compliance Code unknown
Total Number of Contacts 15
Pitch 406.4μm
Contact Finish - Mating AU
Subcategory Headers and Edge Type Connectors
Fastening Type Latch
HTS Code 8536.69.40.40
Number of Rows 1
Color Natural
Number of Positions 15
Connector Type Outer Shroud Contact, Plug, Solder
ECCN Code EAR99

Physical

Insulation Material LIQUID CRYSTAL POLYMER (LCP)
Mount Free Hanging
Contact Plating Gold
Contact Material PHOSPHOR BRONZE
